Please check the following:

Is the power cord or plug damaged?

Check other household appliances.

Check the light in another socket.

Carefully turn the light on its side.

Ensure the power cord is plugged into the centre of the base.

Carefully lay the cord through the indicated groove ensuring it does not become twisted.

Place the magnetic disc in the centre of the base.

Stand the light upright ensuring the cord remains in the slot.

Check the dimmer switch

Press the power button to switch on.

Hold the switch down to use the dimmer switch.

Check wheel carriage plates

Check that the wheel carriage plates are screwed together currently.

Follow the procedure image for correct assembly.

Disconnect the carriage plates

Ensure the following before starting the checks.

Ensure the light is at the top before carrying out the checks. Failure to do this will cause the weight to drop.

Use Hex key provided to remove the three screws.

Be careful to capture all screws when they are loosened.

Hold the heat sink at all times when removing from the upright.

Ensure the red tape on the plates covering the contacts has been removed.

Align the square shapes and screw holes on the heat sink arm and the upright.

Press the two parts together with one hand.

Loosely screw in the three screws.

Recheck alignment.

Proceed to screw until securely clamped.

Unplug the light and leave for 5 minutes.

Plug the light in and switch on.

Check wheel carriage plates

Check that the wheel carriage plates are screwed together currently.

Follow the procedure image for correct assembly.

Disconnect the carriage plates

Ensure the following before starting the checks.

Ensure the light is at the top before carrying out the checks. Failure to do this will cause the weight to drop.

Use Hex key provided to remove the three screws.

Be careful to capture all screws when they are loosened.

Hold the heat sink at all times when removing from the upright.

Ensure the red tape on the plates covering the contacts has been removed.

Reassemble the carriage plates

Align the square shapes and screw holes on the heat sink arm and the upright.

Press the two parts together with one hand.

Loosely screw in the three screws.

Recheck alignment.

Proceed to screw until securely clamped.

Please check the following

Is the power cord or plug damaged?

Check other household appliances.

Check the light in another socket.

Carefully turn the light on its side.

Ensure the power cord is plugged into the centre of the base.

Carefully lay the cord through the indicated groove ensuring it does not become twisted.

Place the magnetic disc in the centre of the base.

Stand the light upright ensuring the cord remains in the slot.

Press the power button to switch on.

Hold the switch down to use the dimmer switch.

Unplug the light and leave for 5 minutes.

Plug the light in and switch on.

Check wheel carriage plates

Check that the wheel carriage plates are screwed together currently.

Follow the procedure image for correct assembly.

Ensure the red tape on the plates covering the contacts has been removed.

Disconnect the carriage plates

Ensure the following before starting the checks.

Ensure the light is at the top before carrying out the checks. Failure to do this will cause the weight to drop.

Use Hex key provided to remove the three screws.

Be careful to capture all screws when they are loosened.

Hold the heat sink at all times when removing from the upright.

Reassemble the carriage plates

Align the square shapes and screw holes on the heat sink arm and the upright.

Press the two parts together with one hand.

Loosely screw in the three screws.

Recheck alignment and proceed to screw until securely clamped.

How to use the dimmer

Press the power button to switch on.

Hold the switch down to use the dimmer switch.

How to assemble your Dyson light

Connecting the upright and base.

Stand the light on a flat surface.

Insert the upright into the base.

Once the upright is inserted, fix screw firmly in place using the Hex key provided.

Remove the red tape from the mounting plates to expose the electrical contacts.

Align the square shapes and screw holes on the heat sink arm and the upright.

Press the two parts together with one hand.

Loosely screw in the three screws.

Recheck alignment.

Proceed to screw until securely clamped.

Remove the red tape on detachable arm.

Remove transparent tape on upright and weight.

Plug the cord into the centre of the base.

Carefully lay the cord through the indicated groove ensuring it does not become twisted.

Place the magnetic disc in the centre of the base.

Stand the light upright ensuring the cord remains in the slot.

How to reposition the Dyson light

The LED head can be positioned directionally in 3 axes.

Only use the heat sink arm to reposition.

CSYS Floor user guide
