Replacing the remote control battery

Replace the battery with type CR 2032.

Please follow the steps in the video.

Ensure the correct button on remote is being pressed

On/Off

Airflow

Oscillation

Point the remote directly at the front of the machine while pressing the button.

Replace the battery

Loosen the base and pull it away from the remote. Replace the battery with type CR 2032.

Test the machine

Use the middle control toggle to adjust the speed of the airflow.

Test the machine

Switch off and unplug the machine.

Unplug the machine for at least 5 seconds or until the LED goes out.

Plug the machine back in and retest.

Try the button on the Main body.

On/Off

Oscillation

Airflow

Ensure the correct button on remote is being pressed

Point the remote directly at the front of the machine while pressing the button.

On/Off

Airflow

Oscillation

Ensure the correct button on remote is being pressed

On/Off

Airflow

Oscillation

Check that the household electrics are on.

Change the fuse in the machine's plug.

Check the plug and power cord for signs of damage.

Try the machine in a different plug socket.

No power

Check that the household electrics are on.

Check the plug and power cord for signs of damage.

Try the machine in a different plug socket.

Check for blockages

Remove the loop amplifier from the telescopic stand by pulling gently on the loop.

Remove the telescopic stand from the Main body by turning the telescope anti-clockwise.

Check the loop and telescope for any debris or blockages.

Ensure the seal is not damaged or missing and no debris visible around the Main body.

Reassemble and test the machine.

The fan has a strong, smooth airflow when switched on. The airflow should be strong enough to lift a sheet of newspaper past 45 degrees.

Hold a newspaper approximately 2 meters (6' 6'') away from the product with the airflow control dial turned to maximum.

Remove the loop amplifier from the telescopic stand by pulling gently on the loop.

Remove the telescopic stand from the Main body by turning the telescope anti-clockwise.

Check the loop and telescope for any debris or blockages.

Ensure the seal is not damaged or missing and no debris visible around the Main body.

Reassemble and test the machine.

Test the machine

Before switching on, please make sure the fan is positioned so that the airflow or oscillation is not obstructed.

Switch the machine on.

When in the ‘on’ position the ON/OFF button should have a blue LED light surround.

Check the feet are attached correctly

Ensure all the feet are attached to the base of the machine.

Place the fan on a flat, non-slip surface.

Ensure the correct button on remote is being pressed

On/Off

Airflow

Oscillation

Ensure the correct button on remote is being pressed

On/Off

Airflow

Oscillation

Point the remote directly at the front of the machine while pressing the button.

Select a different option on the remote

Point the remote directly at the front of the machine while pressing a different option.

Change the remote battery

Replace the battery with type CR 2032.

Please follow the steps in the video.

Test the machine

Switch off and unplug the machine.

Unplug the machine for at least 5 seconds or until the LED goes out.

Plug the machine back in and retest.

Try the button on the Main body.

On/Off

Airflow

Oscillation

Wipe the machine

The following areas should be checked and cleaned to maintain the machine's performance.

Loop amplifier - clean with a dry cloth.

Main body - clean with a dry cloth

Shroud - clean with a dry cloth or soft brush

Test the machine

This issue can occur if the machine is running and the power is cut e.g. plug pulled out, power cut etc.

Unplug the machine for at least 5 seconds or until the LED goes out.

Plug the machine back in and retest.

Test the machine

This issue can occur if the machine is running and the power is cut e.g. plug pulled out, power cut etc.

Unplug the machine for at least 5 seconds or until the LED goes out.

Plug the machine back in and retest.

Unplug the machine for at least 5 seconds or until the LED goes out.

Plug the machine back in and retest.

Test the remote control

Point the remote directly at the front of the machine while pressing the button.

On/Off

Airflow

Oscillation

Assemble your machine

Lower the Main body onto the base, aligning the arrows.

Turn the base clockwise until it clicks into place.

Lower the telescope onto the base, aligning the arrows.

Once aligned, turn the telescope clockwise to lock.

Lower the loop amplifier onto the telescope.

The remote control can be magnetically attached to the top of the loop.

Power

To operate, point the remote control toward the front of the base and press the standby ON/OFF button.

Alternatively press the standby ON/OFF button on the Main body.

Please note, the remote control can be magnetically attached to the top of the loop.

Oscillation

Toggle oscillation on or off with the remote.

Airflow

Airflow can be set by the airflow buttons on the remote.

Adjust the loop

Lift or push air loop up or down for required airflow height.

1. This is the Standby button on the appliance and it is used to turn the machine on/off.
2. This is the oscillation button on the appliance and it is used to start/stop the fan turning.
3. This is the central airflow control on the appliance and it is used to adjust the speed of the airflow.

Serial number location

The serial number can be found on the base of the machine.

How to tilt the loop

Gently move the loop backward or forward for the required airflow angle.

Please open the PDF for the user guide.

Remote controls

On/Off

Oscillation

Airflow

Cleaning your Dyson machine

The following areas should be checked and cleaned to maintain the machine's performance.

Loop amplifier - clean with a dry or damp cloth.

Main body - clean with a dry cloth

Shroud - clean with a dry cloth or soft brush
